Lesson 3: Heads or Tails
About this lesson
This is the third in a series of lessons to transition from visual coding to text-based coding with a general-purpose programming language.
Year band: 5-6, 7-8Curriculum Links Assessment
Links with Digital Technologies Curriculum Area
|Processes and Production Skills||5-6||
Design, modify and follow simple algorithms involving sequences of steps, branching, and iteration (repetition) (ACTDIP019)
Design algorithms represented diagrammatically and in English, and trace algorithms to predict output for a given input and to identify errors (ACTDIP029)
Implement and modify programs with user interfaces involving branching, iteration and functions in general-purpose programming language (ACTDIP030)
Students undertake a self-reflection of the programming task. The teacher can use the completed self-assessments to assist in summative assessment.
In groups, think of some of your favourite tabletop or video games, and complete a table like the one below by answering these questions:
- Does the game have any random element? Something that is left to chance?
- What mechanism is used to generate the randomness?
The first few rows are completed as examples.
|Game||Random element(s)||Mechanism to generate randomness|
|Monopoly||Which square the player lands on||Dice roll|
|Chance cards||Shuffled cards|
|Chess||No random element (except for starting player)|
|Matching puzzle phone game||Order of arrival of pieces to match||Game code chooses piece types|
|First person shooter game||Spawn positions of players||Game code chooses locations|
|Locations and types of upgrades||Game code chooses locations and types|
|AI of enemies||Game code chooses behaviours with a mix of strategy and randomness|
You may want to take this one step further in a class discussion:
Q. A computer often makes thousands of ‘random’ choices when you play an electronic game. How does it choose a random puzzle piece, for example?
A. When a program seems to choose a random puzzle piece, it’s because each piece type has been assigned a number. This is like rolling a die to select which piece type will appear next.
Q. But there’s no dice inside a computer. Can it really choose random numbers?
A. For a computer to come up with a truly random number, it must gather complex data from the world outside, such as fan noise. Computers can also make ‘pseudorandom’ numbers, which can appear to be random but are generated in sequence by an algorithm and a seed value. How random numbers are generated is quite a controversial topic, because it applies to encryption for security.
Francois Philipp/flickr, Creative Commons BY 2.0
Learning map and outcomes
In this lesson, students will:
- explore the design of a simple game combining user input and random number generation
- plan and code a Heads or tails game, where the user tries to guess what the computer will throw.
Begin by watching the overview video below:
As a class, or in teams, discuss what the Heads or tails program will do, then design the program as a flowchart. Effective designs may vary, for example, the program might toss the coin first, then ask the user for their guess.
Here is one solution:
Image: Flowchart for Heads or tails game
Once the flowchart is complete, write the program in pseudocode (structured English).
BEGIN Display “Pick heads or tails:” guess ← input from user computerPick ← random choice between ‘heads’ or ‘tails’ If guess = computerPick then Display “You guessed it.” Else Display “Better luck next time.” End if END
Program designers use pseudocode (also called structured English) before coding an algorithm in a real, specific programming language.
The purpose of pseudocode is to clearly understand and communicate an algorithm, regardless of the final language used. Because it translates more readily into real code, it is often more popular than a flowchart.
Pseudocode has few strict rules, but here are some helpful hints to get started:
- Begin your algorithm with BEGIN. End it with END.
- Use a left-pointing arrow (←) to indicate assigning a value to a variable.
eg. income ← 5 × 12 The variable income will now contain the value 60.
At Years 7 and 8, the Australian Digital Technologies curriculum specifies: ‘Design algorithms represented diagrammatically and in English …’ (ACTDIP029). This is further specified as ‘structured English’ in Years 9 and 10 (ACTDIP040).
For more on setting up and choosing a language, see Setting Up.
Step 1: Coding the game
Step 2: Dice roll
Now that you can toss a coin, the video below challenges you to code a 6-sided dice roll.
Try it yourself before finishing the video or checking the solution code below. You may want to design your program with a flowchart or pseudocode first.
Students may work at vastly different paces when doing general-purpose programming, and some may seem to be quicker at spotting problems than others.
Try these strategies with your students:
- Pedantic computer: Think of the computer as a really pedantic person. It usually won’t cooperate if important punctuation (syntax) is missing, if something is spelled differently in two places, or even with the wrong upper or lower case.
- Pair programming or ‘Ask three before me': Often it just takes a fresh pair of eyes to spot errors or bugs in a program. Before asking the teacher the student checks with other students.
- Trace errors: The computer always runs the program in order, line-by-line, according to the code. Study each line one-by-one and ask, ‘What does this line do?’ Consider writing down the values of variables as you go.
- Tinker: Encourage students to tinker with the code. Ask, ‘What would happen if I changed this?’ Alter a part of the code or add a new feature, predict what might happen, and run it to see. You can always put it back again if something goes wrong.
These challenges use the skills covered so far. By writing or modifying their own programs, students have an opportunity to demonstrate Application and Creation.
How about a program to help you pick who gets to go first when playing a board game? The program should randomly pick one name out of five names.
Note: You don’t need to ask the user to enter all the names. They can be built into the program (or ‘hard-coded’).
- Write out the algorithm in pseudocode first.
Challenge early finishers to improve the program. Now it will ask the user to enter the five names at the start, store each one in a variable, then randomly choose one of them to display.
Mad Libs is a word game where you are asked for some words and then the computer, or another person, creates a silly sentence or story by using your words to fill in blanks. For example:
Enter your name: Bill Enter your favourite place: Paris Enter your favourite sport: soccer Enter an exclamation: Ouch! Enter an adjective: hairy Bill was playing soccer in Paris when a hairy bicycle crashed into him. ‘Ouch!’ said Bill.
By asking for more than one place, or more than one sport, you can make the story more random by choosing just one response.
Challenge 3 (Optional)
Armed with the skills to use branching (from Lesson 2), you can write a choose your own adventure story. By adding variables, you’re already making a smarter story than is possible using slide presentation software. Maybe you can even add a random element to your game.
